ECN48-P
Noise-Cancelling Behind-the-Head Heavy-Duty Headset
Robust hearing protection headset with neckband, microphone and built-in speakers, 13-pin connector, IP54, NRR 28dB, Hytera Logo (RoHS) (REACH) – applicable for HP6, HP7, PDC550, PDC680, PT590, PTC680
Highlights
Functions
Technical Specifications
General
- PTT cycles
- ≥ 100,000
- Operating temperature
- -30 to +60°C
- NRR
- 28dB
- IP rating
- IP54
- Weight
- about 463g
Speaker specifications
- Sensitivity
- 76±4 dB/0.2 W @ 50cm 1 kHz
- Rated power
- 200mW; max: 500mW
- Resistance
- 2x32 Ω ±15% @ 1 kHz
Microphone specifications
- Sensitivity
- -52±3 dB @ 1 kHz 3V 2.2k 0 dB = 1 V/Pa
